Tool microscope and projector
External dimensions, thickness, nose radius, edge profile and other visible geometry.
Quality Checks Tied to the Order
Inspection criteria follow the confirmed tool specification, order batch and records agreed before production or dispatch.
Inspection Starts With the Agreed Specification
A measurement is useful only when it is compared with the correct model, drawing or approved order detail. We first confirm what needs to be checked and how the result will be recorded.
Equipment and the Checks It Supports
The inspection method is selected according to the characteristic that can affect identification, compatibility or performance.
Metallographic microscope
Substrate structure and prepared sample review when the order or issue requires it.
Rockwell hardness tester
Substrate hardness checks against the applicable internal requirement.
Coating thickness gauge
Coating thickness checks for the quoted grade and production batch.
From Approved Detail to Shipment Record
The process keeps the specification, inspection point and released order connected.
Confirm the reference
Model, drawing, grade, chipbreaker, quantity and any critical dimension.
Set the inspection point
Choose the dimensions or material characteristics relevant to the order.
Check the batch
Record the agreed measurements and keep the batch identifier with the result.
Verify packing details
Check model, grade, quantity, label and packaging against the approved order.
Release with evidence
Provide the agreed report, product photographs or short video before dispatch.
A Quality Concern Starts With Evidence
We do not assume a cause from one photograph. Send the clearest information available so the supplied item and machining conditions can be reviewed together.
Tool identityFull code, grade, chipbreaker, batch or order reference.
Application contextWorkpiece material, operation, holder or cutter and machine setup.
Problem evidenceCutting edge, chips, machined surface and cutting-condition photographs.
Agreed specificationQuotation, approved sample detail, label and packing requirement.
Send the Tool Details for Review
A model code helps, but a clear photo, drawing or machining problem is enough to start.
