MCLNR Turning Tool Holders
Compare the listed sizes and interfaces, then send your current model code or drawing for a matching tool.
external turning and facing with compatible CNMG 12 inserts
External turning holder
- System entries
- 3
- Compare
- Size · interface
- Send us
- Code / drawing
Holder Designation
Holder Models & Interfaces
Nominal holder references. Confirm machine interface, pocket, clamping parts and full designation before substitution.
Swipe or scroll horizontally to view every column.
| Select | Holder reference | Shank mm | Length mm | Insert family |
|---|---|---|---|---|
| MCLNR/L2020K12 | 20 x 20 | 125 | CNMG12 | |
| MCLNR/L2525M12 | 25 x 25 | 150 | CNMG12 | |
| MCLNR/L2525M16 | 25 x 25 | 150 | CNMG16 |
No listed models match your search. Try a shorter code or describe your requirement.
Select a model above. You can also use the general quote button at the top of this page.
Have an existing part number or drawing? Include it in your inquiry for a direct match.
Compatibility Check
Holder, Insert & Clamp Matching
Confirm the insert family and size, holder hand, seat, screw, shim and clamp before ordering a replacement.
Family geometry guide
Use this outline to identify the shape and dimensions to compare with your existing tool.
Swipe or scroll horizontally to view every column.
| Matching item | What to confirm |
|---|---|
| Insert | Confirm the complete CNMG 12 designation and nose radius. |
| Hand | Confirm right-hand or left-hand cutting direction. |
| Shank | Match the turret or tool block opening. |
| Clamping parts | Confirm clamp, screw and shim against the quoted holder. |
Selection Checklist
Choose the Right Configuration
Compare the listed model with the actual part and machine setup.
Swipe or scroll horizontally to view every column.
| Check | What to provide or compare |
|---|---|
| Turret | Match the listed 20 × 20 or 25 × 25 mm shank to the machine tool block. |
| Insert | Provide the full CNMG 12 designation and grade. |
| Hand | Confirm right/left hand and tool approach. |
Tooling Package
Match the Cutting Tool to the Holder
MCLNR / MCLNL holder + CNMG 12 insert + matching clamp set
Quote as one set
Quote the holder and the specified CNMG inserts; clamps, shims and screws are separately identified.
Fit check
Match shank size, hand, CNMG 12 seat and the selected clamp assembly.
Related Products
Ordering Support
Frequently Asked Questions
What should I send for a quotation?
Send MCLNR/L code, turret opening, holder hand, CNMG insert size and quantity.
Are the matching parts included?
The quotation lists the selected cutting tool, holder or body, and any specified clamping parts separately.
Can I request another size or configuration?
Yes. Send the existing full code or a dimensioned drawing so the proposed configuration can be checked.
Specification-Led Quotation
Discuss Your Application
Send your model, material, operation and quantity.
We will review the tool interface and quotation variables before confirming an offer.
