Vextrex CNC Tooling Model Catalog
Search 247 documented model designations across turning, milling, grooving, drilling and solid end mills. Threading and toolholder families are included as inquiry references. Confirm the final configuration before ordering.
No form required to download.
Download one guide for your tooling search
Use the family tables and matched-tool prompts to prepare an inquiry. Exact variant, cutting data and commercial terms are confirmed for the quotation.SEARCHABLE MODEL CATALOG
Vextrex CNC Tooling Model Catalog 2026
Full model codes, printed dimensions and original source grade marks for 36 documented families. Threading and toolholding are shown as inquiry references.
- Pages
- 20
- Documented families
- 36
- File size
- Under 10 MB
NEED A SPECIFIC CONFIGURATION?
Request a Model Check
Send your complete code, tool photo or workpiece drawing. We check fit, available configuration and the details needed for a quotation.
- Model code
- Optional
- Drawing
- Accepted
- Matched set
- On request
Search the technical model matrix
Find documented dimensions and source grade recommendations for turning, milling, grooving and drill inserts. Confirm the quoted setup before substitution.Find the family, then confirm the exact tool
Use a code for a replacement review, or send your workpiece material and drawing for a new application. A listed family is a sourcing and selection starting point; grade, coating, fit and supply terms are confirmed for the quoted configuration.
The guide organizes seven current tooling groups by nominal size and matching tool interface. Similar-looking components are checked as a complete set before substitution.
- 01
Turning inserts
Negative and positive insert families.
- 02
Milling inserts
Shoulder, high-feed, round and square formats.
- 03
Drilling tools
Indexable inserts and matched drill bodies.
- 04
Grooving and parting
Width-matched inserts and holders.
- 05
Threading inserts
External and internal BSPT references.
- 06
Solid carbide end mills
Four-flute and aluminum three-flute families.
- 07
Toolholders and systems
Turning holders, boring bars, cutter bodies and BT40-ER32 clamping.
From catalog code to a checkable quotation
- FindLocate a family or full model designation.
- SendShare the code, label photo or drawing with your application.
- ConfirmWe verify grade direction, fit, availability and commercial terms.
