Product family view
Grooving / parting / MGMN
MGMN Grooving Inserts
Find the right MGMN by complete model code, dimensions and catalog grade. Search the table below or send your current code for a match.
external grooving and profile work with a compatible grooving holder
Grooving Insert
- Catalog models
- 6
- Dimensions
- INSL · CW · S · RE
- Catalog grades
- 1 options
Model Reference
Catalog Models & Dimensions
Search by complete designation, compare dimensions and select a model to include it in your inquiry.
How to choose
1 · Size: match the complete model code and the listed dimensions, including corner radius where shown.
2 · Grade: compare SP1201B. R means catalog recommended; O means catalog order option.
3 · Fit: include your workpiece material and holder or cutter code when requesting a quote.
Swipe or scroll horizontally to view every column.
| Select | Full model | INSL (mm) | CW (mm) | S (mm) | RE (mm) | Catalog grade mark |
|---|---|---|---|---|---|---|
| MGMN200-M | 16 | 2 | 4 | 0.2 | SP1201B (R) | |
| MGMN300-M | 21 | 3 | 4.8 | 0.4 | SP1201B (R) | |
| MGMN400-M | 21 | 4 | 4.8 | 0.4 | SP1201B (R) | |
| MGMN500-M | 26 | 5 | 5.8 | 0.8 | SP1201B (R) | |
| MGMN300-GS | 21 | 3 | 4.8 | 0.4 | SP1201B (R) | |
| MGMN400-GS | 21 | 4 | 4.8 | 0.4 | SP1201B (R) |
No listed models match your search. Try a shorter code or describe your requirement.
Select a model above. You can also use the general quote button at the top of this page.
Need another size? Search all catalog models →
Pocket Compatibility
Insert, Pocket & Tool Matching
Confirm the insert size, seat, clamping method and complete holder, cutter or drill-body designation before ordering a replacement.
Swipe or scroll horizontally to view every column.
| Matching item | What to confirm |
|---|---|
| Holder family | Compare MGMN width and seat with the MGEHR / MGEHL grooving holder. |
| Groove geometry | Provide groove width, depth, shoulder clearance and required hand. |
| Clamping set | Confirm the insert seat and clamping parts for the chosen holder. |
Grade and Geometry
Workpiece, Geometry & Grade Selection
Operation, workpiece group, cutting continuity, coolant, machine stability and finish target determine the quoted geometry, grade and coating.
Swipe or scroll horizontally to view every column.
| Selection input | Quotation requirement |
|---|---|
| Operation | external grooving and profile work with a compatible grooving holder |
| Tool interface | Match the complete holder or cutter designation and insert seat. |
| Workpiece | Identify alloy, hardness condition, interruption and required finish. |
| Quotation | Confirm geometry, grade, coating, quantity and destination. |
Application Inputs
Select by Workpiece and Cut
Tell us the workpiece group and operation stage. We then check the available grade, edge, coating and machine setup for the quoted tool.
Workpiece groups
- PSteel
- MStainless steel
- KCast iron
- NNon-ferrous / aluminum
- HHardened materials
Machining stage
- FinishingSurface finish and dimensional control priority
- MediumBalanced general machining
- RoughingMaterial removal and edge strength priority
Tooling Package
Match the Cutting Tool to the Holder
MGMN insert + matching MGEHR holder
Quote as one set
Insert or cutting tool, holder/body, and spare screw, clamp or wrench only when itemized in the quotation.
Fit check
Verify full designations, seat or shank, hand, screw and machine interface before ordering.
Related Products
Ordering Support
Frequently Asked Questions
What should I include in an inquiry?
Send the full MGMN300 designation, holder or cutter code, material, quantity and drawing where available.
Does the photograph confirm the supplied variant?
No. Confirm the complete designation, grade, coating and tool interface in the quotation.
Can I request a sample?
Request a sample for the intended specification. Availability, sample terms and delivery timing are confirmed in the quotation.
Specification-Led Quotation
Discuss Your Application
Send your model, material, operation and quantity.
We will review the tool interface and quotation variables before confirming an offer.
